SUS314 10mm Thickness For High Temperature Material AISI 310S 310Si2 Stainless Steel Plate

Name: SUS314 10mm Thickness For High Temperature Material AISI 310S 310Si2 Stainless Steel Plate
Brand: TSINGSHAN
Price: 4.45 USD

China SUS314 10mm Thickness For High Temperature Material AISI 310S 310Si2 Stainless Steel Plate wholesale

Brand Name : TSINGSHAN

Model Number : 314 0Cr25Ni20Si2

Certification : ISO MTC

Place of Origin : China

MOQ : 100KGS

Price : USD4.45/KG

Payment Terms : L/C, T/T

Supply Ability : 50000KGS

Delivery Time : 7 Days

Packaging Details : Wooden Box

Thickness : 1.0-100mm

Origin : TISCO, Southwest, ESS, Bao steel, etc

Manufacture Technology : Cold / Hot Rolled

Type : Plate,Sheet

Company Type : storage company

Product Type : Stainless Steel Plate

Package : Standard Seaworthy Package

Surface Treatment : No.1

Item : ISO9001 Standard

Oem Service : Available

Payment Term : T/T, L/C

Surface : Brushed NO.4 NO.1

Weight Of Coil : as per final net weight

Material : Stainless Steel

Contact Now

SUS314 10mm Thickness For High Temperature Material AISI 310S 310Si2 Stainless Steel Plate

Product Description

Product Name	Stainless Steel Plate
Material	200 Series: 201, 202
	300 Series: 304, 304L, 304H, 310S, 316, 316L, 317L, 321,310S,309S,2205,2507,2520
	400 series: 410, 410S,420, 430, 431, 440A,904L
	Others: 2205, 2507, 2906, 330, 660, 630, 631, 17-4ph, 17-7ph, S318039904, etc
	Duplex Stainless Steel: S22053, S25073, S22253, S31803, S32205, S32304
	Speicial Stainless Steel: 904L, 347, 347H, 317, 317L, 316Ti, 254Mo
Standard	AISI, ASTM, DIN, GB, JIS, SUS
Technology	Cold Rolled, Hot Rolled
Length	100~1200mm or as Customer's Requirement
Thickness	Cold Roll: 0.1~3mm Hot Roll: 3~100mm
Width	100~2000mm
Surface	BA, 2B, 2D, 4K, 6K ,8K, NO.4, HL, SB, Embossed
Other Choices	Leveling: improve flatness, esp. for items with high flatness request.
	Skin-Pass: improve flatness, higher brightness
	Cutting: Laser Cutting, Help the Customer to cut the required size
Protection	1. Inter Paper Available
Protection	2. PVC Protecting Film Available

It can withstand repeated heating below 1150 °C, and the temperature can reach 1200 °C. It has high high-temperature strength, oxidation resistance, and carburization resistance. It is sensitive to sulfur-containing atmospheres and has a tendency to embrittle the precipitated phase at 600-800 °C. It is suitable for making various furnace components under stress.

Stainless Steel 314 Sheets & Plates Specifications

Standard :	ASTM A240 / ASME SA240
Width :	1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Thickness :	4 mm To 100 mm
Length :	2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Surface :	2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc
Form :	Sheets, Plates, Coils, Slatting Coils, Perforated Coils
Finish :	Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)

1.4841 (314) stainless steel is a high-temperature alloy that is known for its excellent resistance to oxidation and carburisation. While it is a single variant of stainless steel, it is sometimes referred to by other names depending on the specific application or manufacturer. Some of the different names you may come across include:

AISI 314
UNS S31400
W.Nr. 1.4841
EN X15CrNiSi25-20
JIS SUS314

Product Description

chemical constituents	Carbon (C)	Silicon (Si)	manganese(M)	Phosphorus (P)	Sulfur (S)	Chromium (Cr)	Nickel (Ni)
the smallest		1.5				24	18
maximum	0.2	2.5	1.5	0.035	0.03	27	21
tensile strength	σb (MPa):≥590
Conditional yield strength	σ0.2 (MPa):≥295
Elongation	δ5 (%):≥35
rate of reduction in area	ψ (%):≥50
hardness	≤187HB
Heat treatment specifications:	1080~1130ºC rapid cooling

314 Stainless Steel Sheets & Plates Equivalent Standard Grade

STANDARD	WERKSTOFF NR.	UNS	JIS
SS 314	1.4841	S31400	SUS 314

SUS314 10mm Thickness For High Temperature Material AISI 310S 310Si2 Stainless Steel Plate

Q1. Where is your factory ?

A1: Our company's processing center is located in Shandong , China. Which is well equipped with kinds of machines, such as laser cutting machine, mirror polishing machine and so on.We can provide a wide range of personalized services according to the customers' needs.

Q2. How do you control quality ?

A2: First step , Please contact with our sales team , talked about the cargo details , if need sample , we can supply the sample for free ; If the sample can reach to requirement , the client can sign the contract with our company;Before shipment , client can inspect the cargo loading and seal the container , we also can accept inspection of the third party ( Such as SGS ,BV etc ) ;

Q3. What are the advantages of your company ?

A3: We have many professionals, technical personnel, more competitive prices and best after-dales service than other seamless lead product companies.

Q4. Can you arrange the shipment ?

A4: Sure we can help you with the shipment. We have forwarders who have cooperated with us for many years

Q5. How about the delivery time ?

A5: It is based on the order, After 5 days of shipment , we will send the documents of customs clearance to you ;After get the cargo , please give feedback to us ;
