1. Item: Inconel600 steel plate, Incone600 steel sheet, UNS NO6600 Steel sheet, UNS NO6600 Nickel alloy steel sheet
2. Size:
Thickness: 0.3-100mm
With: 500mm, 600m, 1000mm, 1500mm, 2000mm, or as required
Length: 1-12m
3. Surface: Mill, bright, polished, annealing, picking, brush, hair line, sand blast, etching, etc
| Item | Inconel600 steel sheet,Inconel600 steel plate,UNS NO6600 Steel sheet,UNS
NO6600 Nickel alloy steel sheet |
| Grade | Inconel600(Ni:72%min,Cr:14%-17%,Cu:0.5max,Fe:6-10%,Mn:1.0max,
Si:0.5max,C:0.15 max) |
| Size | Thickness:0.3-100mm
With:500mm,600m,1000mm,1500mm,2000mm,or as required
Length:1-12m |
| Detail: | Elastic modulus :26 000 ksi
Denisty:8.47g/cm3
Heating capacity :0.427 J/g-°C
Thermal conductance:21.8 W/m-K
Melting point :1354 - 1413°C |
| Specialty | 1. Has good resistance to reduction, oxidation, nitrogen medium corrosion performance,
2. When at room temperature and high temperature has good resistance to stress
corrosion cracking performance
3. Has good resistance to dry chlorine and hydrogen chloride gas corrosion performance |
| corrosion resistance | Inconel 600 alloy chemical composition to be able to resist a variety of environmental
corrosion. In the content of chromium alloy must be in the oxidation environment
corrosion resistance is better than that of industrial pure nickel, of which high nickel
content and its reduction environment also can maintain considerable of corrosion
resistance. Alloy of nickel content also make the alkali solution with good corrosion
resistance.The alloy to strong oxidizing acid solution with equal corrosion resistance.
However, single dissolved air oxidation is insufficient to ensure full passive state and
freedom from saturated air by inorganic acid certain concentration organic acid erosion |
| Application | 1. The pressurized water reactor steam generator tube;
2. Sodium hydroxide heat exchanger;
3. Used in the manufacture of photographic equipment and film flushing processing
components;
4.Production of vinyl chloride oxide generator internal components; 5. Used for flight
recorder of banding. |
| Price term | Ex-Work,FOB,CNF,CFR,CIF,etc |
| Export to | USA,Iran,India,Ukraine,Singapore,Indonesia,Spain,Brazil,Korea,Thailand,Canada,Sadui
Arabia,Viet Nam,Oman,Peru,Spain,Russia,Italy,Chile,etc |
| Contact | If you have any question,please feel free to contact us. |
Delivery Conditions and Finishes
Plates, sheets and strips of ASTM B168 UNS N06600 may be furnished in the following conditions & surface finishes:
- Inconel 600 hot-rolled plate: annealed; or as-rolled.
- Inconel 600 hot-rolled sheet: annealed.
- Inconel 600 cold-rolled sheet: annealed; or hard.
- Inconel 600 cold-rolled strip: annealed; skin-hard; quarter-hard; half-hard; or three-quarter-hard; hard; or spring.
Chemical Requirements
| Ni | Cr | Fe | Mn | C | Cu | Si | S |
| ≥72.0 | 14.0-17.0 | 6.0-10.0 | ≤1.0 | ≤0.15 | ≤0.50 | ≤0.50 | ≤0.015 |
*Unit: %; The chemical analysis shall be conducted in accordance with ASTM B880.
Mechnical Properties
| Condition | Tensile Strength,
min., ksi [MPa] | Yield Strength,
min., ksi [MPa] | Elongation min.,
in 50 mm, % |
| *A | 80 [550] | 35 [240] | 30 |
| *B | 125 [860] | 90 [620] | 2 |
*A refers to Inconel 600 plate, sheet, strip furnished in annealed condition.
*B refers to Inconel 600 materials furnished in hard condition.
*The hardness of Inconel 600 shall be tested and specified.
