ASTM A480M AISI 444 EN10088-2(1.4521) Ferritic Stainless Steel Sheet 1.2*1219 Used For Corrosion Resistance
444 is a low carbon, dual stabilised, molybdenum containing ferritic stainless steel with good ductility, toughness and resistance to sensitisation, even in the welds. With 18% chromium and 2% molybdenum, the steel has good pitting resistance and crevice corrosion resistance, similar to 316 and good general corrosion resistance and oxidation resistance, similar to 316 in most environments. Being a ferritic stainless steel, 444 is not susceptible to Stress Corrosion Cracking. Annealed 444 is ductile and can be formed using a wide range of roll forming or mild stretch bending operations as well as the more common drawing and bending operations. 444 does not harden excessively during cold working.
The steel has limited weldability and should not be used in the as-welded condition for dynamic or impact loaded structures. As with most ferritic stainless steels, 444 can undergo grain growth in the heat affected zone of weldments, which may adversely affect the mechanical properties in these zones. Applications involving welded CS444 are thus generally limited to a thickness of 2.5mm.
CS444 has good pitting resistance and is thus suitable for roofing and cladding in marine environments, as well as hot water tanks and geysers, heat exchanger tubing and food processing equipment.
SPECIFICATIONS&TOLERANCES
ColumbusStainless(Pty)LtdsuppliesCS444toASTMA240(444)and
EN10088-2(1.4521).
444 Stainless steel
1. Chemical composition
| C | Si | Mn | P | S | Ni | Cr |
| max0.025 | max1.00 | max1.00 | max0.04 | max0.03 | --- | 17.00-20.00 |
2. Mechanical properties
| Yield Strength | Tensile | Elongation | Hardness (HV) | Hardness (HRB) |
| ≥245 | ≥410 | ≥20 | ≤230 | ≤96 |
3. Standard: AISI, ASTM, GB, EN, DIN, JIS
4. Surface: 2B, NO.1, BA, NO.4, Hairline, SB, Mirror finish, Anti-skid, Cherkered etc.
5. Size: Thickness: 0.3-3mm (cold rolled), 3-40mm (hot rolled)
Width: 1000mm or 1219mm or 1240mm for cold rolled, 1500mm for hot rolled.
Length: As customers' request.
6. MOQ: 1 Ton
7. Payment terms: T/T or L/C
8. Packing: Seaworthy package with wooden or Iron pallets with the paper and the steel strip, or as customers' request.
9. Delivery time: Usually about 7 days after we confirming the order, or according to your quantity.
If you have any question or demand, pls feel free to contact me.
