441 Stainless Steel Sheet SUS441 1.4509 0.4-4mm 2D Surface 1250mm For Automotive

Name: 441 Stainless Steel Sheet SUS441 14509 044mm 2D Surface 1250mm For Automotive
Brand: MITTEL TISCO BAO STEEL
Price: 1.95 USD

China 441 Stainless Steel Sheet SUS441 1.4509 0.4-4mm 2D Surface 1250mm For Automotive wholesale

Brand Name : MITTEL TISCO BAO STEEL

Model Number : 441 1.4509

Certification : SGS ISO MTC

Place of Origin : China

MOQ : 100KGS

Price : 1.95 USD/KG

Payment Terms : L/C, T/T

Supply Ability : 50000KGS

Delivery Time : 7 Days

Packaging Details : Wooden Pallet

Application : decoration,Construction,Medical instruments,metallurgy

Grade : 400 Series

Type : Plate,stainless steel sheet

Standard : JIS,ASTM,AISI,DIN

Length : 1000-6000mm,Customer's Request

Width : 1000-2000mm

Thickness : 0.3-16mm

Surface : BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D

Edge : Mill Edge,Slit Edge

Technique : Cold Rolled Finish

Price term : CIF CFR FOB EX-WORK

Packing : Standard Sea-worthy Packing

Contact Now

441 Stainless Steel Sheet SUS441 1.4509 0.4-4mm 2D Surface 1250mm Used For Automotive

Type 441 (UNS S44100) in Coil Form

Description
Type 441 is an 18% chromium, dual stabilized ferritic stainless steel with corrosion resistance similar to that of 304/304L stainless steel. This grade may be used in the annealed, cold formed or as-welded condition in applications where other stainless steels such as Type 304/304L and Type 430 are used. Type 441 has good weldability due to titanium and niobium stabilization and has excellent resistance to stress corrosion cracking. Type 441 outperforms Type 409 in both oxidation and corrosion resistance and typical applications include automotive manifolds and exhaust system components. The high temperature strength of Type 441 exceeds that of both Types 439 and 409 stainless steels.

Chemical Composition
Chemical Composition (wt%) limits as specified in ASTM A240*

Element	441
Carbon	0.030
Chromium	17.5-19.5
Nickel	1.00
Manganese	1.00
Silicon	1.00
Nitrogen	0.030
Phosphorus	0.040
Sulfur	0.030
Titanium	0.1-0.5
Niobium	0.3 + (9 x C) min 0.90 max

* Maximum, unless range is indicated

Mechanical Properties
Mechanical property requirements for annealed product as specified in ASTM A240

Property	441
Yield Strength, min. (ksi)	35
Tensile Strength, min. (ksi)	60
Elongation, min. (%)	20
Hardness, max. (Rb)	90

Physical Properties
Physical properties for Type 441 stainless steel

Property	441
Density, lb/in3	0.278
Modulus of Elasticity, psi	29.0 x 106
Coefficient of Thermal Expansion, 68-212˚F, /˚F	5.7 x 10-6
Thermal Conductivity, Btu/ft hr ˚F	12.1
Specific Heat, Btu/lb ˚F	0.11
Electrical Resistivity, Microohm-in	23.1

Data are typical, are provided for informational purposes, and should not be construed as maximum or minimum values for specification or for final design, or for a particular use or application. The data may be revised anytime without notice. We make no representation or warranty as to its accuracy and assume no duty to update. Actual data on any particular product or material may vary from those shown herein.
